Product Image

Arrow Duct Concealing, RO48DMH

8,360.01 SAR 8,360.01 SAR

Arrow Duct Concealing, RO48DMH

Create a new review

Brand: Arrow
Cooling and Heating
Cooling : 49000
Heating : 17600


8,360.01 SAR 8,360.01 SAR 8360.01 SAR

7,269.5652 SR

(0% Off)
  • Brand
  • Cooling Capacity
  • Heating Capacity
  • Color
  • Air Conditioner Type

This combination does not exist.

Add to Cart Buy Now


Arrow Modern Future Co. Arrow Modern Future Co. is a limited liability company established in 2004 under Commercial Registration No. 1010201179 Dated 13/07/14 5 H head office is located in Riyadh and its main activities are trading retail and wholesale of electric and electronic and other home appliances and devices

  • 30-day money-back
  • 7-day returns
  • Shipping: 2-3 Days

Light Weight and Compact Design

With the weight decreases almost '20% and the size shrinks 12.5% in comparison with conventional one, the A6 duct save lots of installation error's and time as well as creates bigger maintenance space.

Flexible Installation and Maintenance

Air inlet from back or from bottom is optional. with the same plate size, which allows flexible change of the air inlet direction. It also features easy-to-remove filter and PCB. making daily cleaning job a breeze.

Quiet Operation

Optimized duct design and the high efficient DC tan motor together offer quiet operation despite of the small structural design.

AeroStic Technology

The unique and innovation AeroStic Technology can automatically detect required airflow volume to different ducting length, and the pre-programmed intelligent algorithm to figure out the necessary static pressure and instructs the DC fan motor to deliver accurate and enough airflow volume to every room. This technology saves lots of manual calculation and testing labors during the installation, while better guarantees the optimal comfort and lower noise for any space that coverer.

specifications :

  • Model Name-RO-48DMH
  • Brand: Arrow
  • Power supply-230V,1Ph,60Hz
  • Cooling(T1):
  • Capacity (Btu/h)- 42200
  • Input(W)- 3430
  • Current(A)- 15.2
  • EER(Btu/h/W)- 12.3
  • Cooling(T3):
  • Capacity (Btu/h)- 37800
  • Input(W)- 4344
  • Current(A)- 19.12
  • EER(Btu/h/W)- 8.7
  • Heating:
  • Capacity(W)- 16900
  • Input(W)- 4694
  • Current(A)- 20.88
  • Type-DC
  • Input(W)- 560
  • Output(W)- 560
  • Speed (Hi/Med/Lo)r/min-1020/800/600
  • Indoor coil (Number of rows)-4
  • Tube pitch(a)*row pitch(b)mm-25.4x22
  • Fin spacing-1.5
  • Fin type-Hydrophilic aluminum
  • Tube outside dia.and type-Φ9.52, Inner groove tube
  • Number of circuits-7
  • Indoor air flow (Hi/Med/Lo) (under rated ESP)- 2630/2050/1450
  • Indoor noise level (Hi/Med/Lo) (under rated ESP)- 51/48/44
  • Indoor unit Dimension (WxDxH)- 1200x625x380
  • Indoor Packing (WxDxH)- 1485x675x460
  • Net/Gross weight-56.8/65.6
  • Design pressure-4.8/1.5
  • Drainage water pipe diameter-ODΦ25
  • Refrigerant piping (Liquid side/ Gas side)- Φ9.52/Φ19(3/8""/3/4"")
  • Controller-Wired control
  • Operation temperature-17~30
  • Room temperature (Cooling)- 17~32
  • Room temperature (Heating)- 0~30"
